FY55J Mini Skid Steer Loaders

Place of Origin:

Qingdao, China

Start port:

Qingdao

Minimum order quantity:

1 set

Certificate:

CE/ EPA / ERURO5

Color:

Yellow ,Orange ,Red, Green, Blue or customized

Brand:

Fullwin or OEM Brand

Delivery time:

10-30 days Based on Order Quantity

Model:

FY55J

Transaction mode:

T/T

Inquiry

Write a Review

Product Details

The FY55J control console is designed with user-friendliness in mind, enabling operators to learn how to use it effectively without the need for extensive and complex training sessions. This thoughtful design ensures that even those with limited experience can become proficient quickly. Additionally, users can select between Kubota and Perkins engines, which allows them to tailor their choice to meet their specific operational needs. This flexibility ensures optimal performance suited to various requirements. The console also provides operators with the ability to achieve precise control over hydraulic actuators, resulting in accurate operation and correct positioning. This level of control not only enhances productivity but also contributes to extending the overall lifespan of the equipment across a wide range of diverse operating environments. As a result, users can experience improved efficiency and reliability in their tasks.

Product Details

细节 (1) (14)

细节 (2) (12)

细节 (3) (13)

细节 (4) (14)

细节 (5) (14)

细节 (6) (13)

Product Parameters

FY55J Mini Skid Steer Loader Specifications
Overall Dimension (mm)	1700920700
Weight (kg )	175
Max Trenching Depth (mm)	900
Single Trenching Width (mm)	155
Chain Rotary Speed (m/min)	154
Max Working Height (mm)	2420
Max Pin Height (mm)	2099
Max Dump Height (mm)	1617
Unloading Distance At Highest Position (mm)	615
Bucket Swing Angle	79°
Bucket Unloading Angle	36°
Opening-closing Angle	43°
Angle Of Departure	30°
Total Height( mm)	1607
The Height From The Ground (mm)	300
Wheelbase(mm)	1065
No Bucket Length(mm)	2200
Total Width(mm)	1033
Bucket Width(mm)	1140
Total Length(mm)	2752
Turning Radius (F) (mm)	2198
Engine	Model	PERKINS 403J-11
	Rated Power（KW/HP）	18.5/25
	Rotation speed（rpm）	3000
Noise（Db）				≤95
Hydraulic System	System Pressure（Mpa）	20
	Working Time（s）	Lifting	Uninstall	reduce
		3.89	1.6	3.35
Configuration parameters	Loading weight (Kg)	300
	Bucket capacity (m3)	0.14
	Maximum lifting force (Kg)	1258
	Walking speed(Km/h)	0-8
	Operating Weight (kg)	1775
	Machine weight (kg)	1450
Main Pump	Qty: 2
Main Pump Flow (L/min)	24.5*2
Auxiliary Pump Flow (L/min)	19.44
Auxiliary Pump	Qty: 1
Main Valve	Qty :4

Product Features

细节 (8) (10)

细节 (9) (7)

细节 (10) (6)

细节 (11) (5)

FAQ

How long is the mini excavator warranty time?

One year.

which certification of mini excavator do you have?

CE, ISO900 1, SGS, etc. expect these for different countries, other certificates required by the customer are agreed upon.

Is it convenient to see visit your factory and how do go there?

Welcome everyone to come to visit our factory, we are in Dezhou city, near Jinan airport. Also, high-speed trains arrive in our city. Make sure your trip date we will arrange it for you.

What are our advantages compared with Manufacturers/Factories?

Competitive Price-we work as the leading dealers of various leading China construction machinery, and are treated with the best dealership prices every year. From numerous comparisons and feedback from clients, our price is more competitive than Manufacturers/Factories.
Quick Response-Our team is consisted of a group of diligent and enterprising people, working 24/7 to respond to client inquires and questions all the time. Most problems can be solved within 12 hours.

How long will our price be valid?

We are a tender and friendly supplier, never greedy for a windfall profit. Basically, our price remains stable throughout the year. We only adjust our price based on two situations:
(1) The rate of USD: RMB varies significantly according to the international currency exchange rates.
(2) Manufacturers/Factories adjusted the machine price, because of the increasing labor cost, and raw material costs.
