Product details of the mini crawler excavator
Product Information
Fullwin Machinery mini crawler excavator is sophisticated in every detail by paying great attention to detail, both in the selection of raw material and in every aspect of production. Customers can be assured of its quality and integrity. Known for its high tolerance, it is highly regarded in the market.
Product Introduction
FW18J Diesel Engine Excavator is a 1.8-ton small excavator that stands out in the market for its low price, lightweight body and convenient maintenance. It is widely loved by users for its compact design, high flexibility and excellent working efficiency. The excavator is widely used in urban and rural engineering projects, including road construction, building foundation excavation, water conservancy projects, mining, etc., and can easily handle the loading of loose materials such as gravel and coal.
FW18J is equipped with high-end configurations such as seamless integral molding design, standard swing arm, imported engine and pump valve motor, heat-insulated and sound-insulated cab, zero tail swing design, and widened crawler tracks to enhance performance in soft terrain. The humanized cab design includes one-button start, radio, cup holder, comfortable seat and headrest armrest, which enhances the control experience. At the same time, the concealed hydraulic oil tank and diesel tank design, as well as the cast iron counterweight block, enhance the safety and stability of the equipment, making it a powerful assistant in various engineering projects.
Product Details
Product Parameters
|
FW18J specifcation |
||
|
The machine operating weight |
1650kg |
|
|
Bucket capcity |
0.025m³ |
|
|
Engine model |
Kubota D722 |
|
|
Type |
Three-cylinder, in-line, water-cooled, four-stroke, mechanical pump, naturally aspirated |
|
|
Rated power |
10.4kW/2500rpm |
|
|
Max torque |
45Nm/2500rpm |
|
|
Displacement |
0.719L |
|
|
Main performance |
||
|
walking speed |
1.8km/h |
2.3/4.5Km/h |
|
Rotation speed |
12-13 |
|
|
Gradeability |
58%（30°） |
|
|
Ground press |
23kPa |
|
|
Bucket digging force |
9kN |
|
|
Arm Digging Force |
5.5kN |
|
|
Oil and coolant capacity |
||
|
fuel tank |
14.5L |
|
|
hydraulic oil tank |
14.5L |
|
|
engine oil |
3.2L |
|
|
Working range |
||
|
Max digging height（mm） |
2955 |
|
|
Max unloading height |
2077 |
|
|
Maximum digging depth |
2017 |
|
|
Maximum vertical depth（mm） |
1610 |
|
|
Maximum digging radius |
3529 |
|
|
Tail radius（mm） |
655 |
|
|
Minimum turning radius |
1812 |
|
|
Bulldozer lift maximum |
236 |
|
|
Maximum sinking depth |
229 |
|
|
Swing arm deflection Angle |
50° |
|
|
Swing arm deflection Angle tothe right |
52° |
|
|
Whole machine size |
||
|
Overall length |
3329 |
|
|
Overall width |
990 |
|
|
Overall height（mm） |
2267 |
|
|
Dozer board height（mm） |
210 |
|
|
Track plate width（mm） |
200 |
|
|
Track gauge（mm） |
790（1100） |
|
|
Track grounding length（mm） |
1190 |
|
|
Minimum ground clearance（mm） |
153 |
|
|
Tail swing radius（mm） |
655 |
|
