Small Skid Steer Loaders for Sale Orange by Fullwin Machinery
Product details of the small skid steer loaders for sale
Product Information
Fullwin Machinery draws inspiration from history to create small skid steer loaders for sale. Our professional quality check team ensures this cost-effective and high performance product. After many years of development, Qingdao Fullwin Machinery Co.,Ltd has been recognized by customers for its good reputation and excellent quality.
Product Details
The FY55J control console is designed with user-friendliness in mind, enabling operators to learn how to use it effectively without the need for extensive and complex training sessions. This thoughtful design ensures that even those with limited experience can become proficient quickly. Additionally, users can select between Kubota and Perkins engines, which allows them to tailor their choice to meet their specific operational needs. This flexibility ensures optimal performance suited to various requirements. The console also provides operators with the ability to achieve precise control over hydraulic actuators, resulting in accurate operation and correct positioning. This level of control not only enhances productivity but also contributes to extending the overall lifespan of the equipment across a wide range of diverse operating environments. As a result, users can experience improved efficiency and reliability in their tasks.
Product Details
Product Parameters
|
FY55J Mini Skid Steer Loader Specifications |
|||||||
|
Overall Dimension (mm) |
1700*920*700 |
||||||
|
Weight (kg ) |
175 |
||||||
|
Max Trenching Depth (mm) |
900 |
||||||
|
Single Trenching Width (mm) |
155 |
||||||
|
Chain Rotary Speed (m/min) |
154 |
||||||
|
Max Working Height (mm) |
2420 |
||||||
|
Max Pin Height (mm) |
2099 |
||||||
|
Max Dump Height (mm) |
1617 |
||||||
|
Unloading Distance At Highest Position (mm) |
615 |
||||||
|
Bucket Swing Angle |
79° |
||||||
|
Bucket Unloading Angle |
36° |
||||||
|
Opening-closing Angle |
43° |
||||||
|
Angle Of Departure |
30° |
||||||
|
Total Height( mm) |
1607 |
||||||
|
The Height From The Ground (mm) |
300 |
||||||
|
Wheelbase(mm) |
1065 |
||||||
|
No Bucket Length(mm) |
2200 |
||||||
|
Total Width(mm) |
1033 |
||||||
|
Bucket Width(mm) |
1140 |
||||||
|
Total Length(mm) |
2752 |
||||||
|
Turning Radius (F) (mm) |
2198 |
||||||
|
Engine |
Model |
PERKINS 403J-11 |
|||||
|
Rated Power（KW/HP） |
18.5/25 |
||||||
|
Rotation speed（rpm） |
3000 |
||||||
|
Noise（Db） |
≤95 |
||||||
|
Hydraulic System |
System Pressure（Mpa） |
20 |
|||||
|
Working Time（s） |
Lifting |
Uninstall |
reduce |
||||
|
3.89 |
1.6 |
3.35 |
|||||
|
Configuration parameters |
Loading weight (Kg) |
300 |
|||||
|
Bucket capacity (m3) |
0.14 |
||||||
|
Maximum lifting force (Kg) |
1258 |
||||||
|
Walking speed(Km/h) |
0-8 |
||||||
|
Operating Weight (kg) |
1775 |
||||||
|
Machine weight (kg) |
1450 |
||||||
|
Main Pump |
Qty: 2 |
||||||
|
Main Pump Flow (L/min) |
24.5*2 |
||||||
|
Auxiliary Pump Flow (L/min) |
19.44 |
||||||
|
Auxiliary Pump |
Qty: 1 |
||||||
|
Main Valve |
Qty :4 |
||||||
